Whole Set Machinery Sale Maize Flour Milling Equipment
1.Cleaning Part
Use magnet separator removing the metal from the raw material.
Virbtating Screen used for separating the impurities.
Destoner-machine used for separating the stone.
2.Peeling and Milling Part
Use the maize peeling machine separate the shell from the maize
Use the roller flour mill milling maize.
Packing the final product
Main features
1.Automatic whole line can save workers, one person can be available for operation.
2.Complete function processing as cleaning maize, peeling maize and grinding maize into maize flour and maize grits.
3.Clean maize to remove stone, metal, sand and all sorts of impurities.
4.Peel maize to remove maize skin, remove maize germ, remove black maize . After cleaning and peeling, it prepares best maize material for further processing into maize flour or grits.
5.You can choose the mesh to make the flours fine as you requirement.
| Maize Flour Milling Machine Specifications | ||||||||
| Type | 5T | 10T | 20T | 30T | ||||
| Capacity(t/d) | 5 | 10 | 20 | 30 | ||||
| Power(kw) | 29 | 74.4 | 84.9 | 97.4 | ||||
| Installation Area(m) | 5*3*3.5 | 10*5*5.5 | 11*5*5.5 | 12*5*5.5 | ||||
| Maize Flour Milling Machine Specifications | ||||||||
| Type | 50T | 80T | 100T | 200T | ||||
| Capacity(t/d) | 50 | 80 | 100 | 200 | ||||
| Power(kw) | 125.35 | 208 | 245 | 530 | ||||
| Installation Area(m) | 14*5*5.5 | 16*5.5*6 | 18*5.5*6 | 24*6*11 | ||||
Certifications
Our Service| Per-sale | Win-win cooperation: 1. Sign the contract 2. Establish mutual benefit, strategic cooperative partnership. | ||||
| In-sale | Installation: 1. Quality and quantity guaranteed 2. Completion of hand over Acceptance: 1. Acceptance test 2. Accepted deliverable Technical training: 1.On-site installation and products training 2. Operation skills training 3.Maintenance training 4. Centralized technical training. | ||||
| After-sale | Technical service: Long time technical serviceAccessories supplying: Supplying spare parts with cost | ||||
Our Company
FAQQ1.What’s your advantage? Why we choose you?
A:20 Years experience of design and manufacture grain and oil machinery.We have the most professional techniques and team. More advantage in price.
Q2.What’s the Payment?
A:T/T would be better with quick transfer and few bank fees. L/C could also be accept, but the procedure is complex and the fee is high. You can also use Western Union and Paypal.
Q3.Are you a factory or trading company?
A:We are a professional manufacturer. We are warmly welcome clients from worldwide to visit our factory and cooperate with us.
Q4: Can you show how the machine works?
A: Certainly, we will send you the Operating video & instruction to you together with machines, to help you use the machines better.
Q5: How can I know your machine works well?
A: Before delivery, we will test and adjust the machine working condition for you, then you can use directly when you get it.
Q6: Do you have ISO certificate?
A: For every model of machine, it has a ISO certificate.
After Warranty Service:Video technical support, Online support, Spare parts, Field maintenance and repair service
Local ServiceLocation:None
Showroom Location:None
Condition:New
Place of Origin:China
Brand Name:Yubei
Production Capacity:5-200T/D
Voltage:380V
Power(W):29-530kw
Weight:Up to specification
Dimension(L*W*H):According to the capacity
Certification:ISO9001
Warranty:1 YEAR
After-sales Service Provided:Field installation, commissioning and training, Engineers available to service machinery overseas
Product name:Whole Set Machinery Sale Maize Flour Milling Equipment
Raw material:Maize, Corn
Application:Grain Processing Line
Usage:Process Maize/corn flour
Type:Grain Processing Equipment
Final products:Super Fine Maize Flour
Color:White & Green
Capacity:5-200TPD
- Packaging Details
- 1.Outside package:plywood case and shipping container
2.Inner package:stretch film.
- Port
- Qingdao,Tianjin,Shanghai
- Picture Example:
-
- Lead Time :
-
Quantity(Sets) 1 - 1 >1 Est. Time(days) 10 To be negotiated
